Product Summary
The HCPL3700SV is an AC/DC to logic interface optocoupler. The input buffer chip is capable of controlling threshold levels over a wide range of input voltages with a single resistor. The output is TTL and CMOS compatible. Its applications include Low voltage detection, 5 V to 240 V AC/DC voltage sensing, Relay contact monitor, Current sensing, Microprocessor Interface, Industrial controls.
Parametrics
HCPL3700SV absolute maximum ratings: (1)storage temperature: -55 to 125℃; (2)lead solder temperature: 260℃; (3)input current average: 50mA; (4)input voltage: -0.5V; (5)output voltage: -0.5 to 20V.
Features
HCPL3700SV features: (1)AC or DC input; (2)Programmable sense voltage; (3)Logic level compatibility; (4)Threshold guaranteed over temperature (0℃ to 70℃); (5)Optoplanar™ construction for high common mode immunity.
