Product Summary
The AD606JRZ is a demodulating logarithmic amplifier with limiter output. It provides both logarithmic and limited outputs. The logarithmic output is from a three-pole post-demodulation low-pass filter and provides a loadable output voltage of +0.1 V dc to +4 V dc.
Parametrics
AD606JRZ absolute maximum ratings: (1)supply voltage VPOS: 9V; (2)Internal power dissipation: 600mW; (3)oprating temperature range: 0 to 70℃; (4)storage temperature range: -65 to 150℃; (5)lead temperature range: 300℃.
Features
AD606JRZ features: (1)logarithmic amplifier performance; (2)limiter performance; (3)low power.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD606JRZ |
|
IC AMP LOG LP 1.2MA 16SOIC |
Data Sheet |
|
|
||||||||||||||
|
AD606JRZ-REEL7 |
|
IC AMP LOG LP 1.2MA 16SOIC |
Data Sheet |
|
|
||||||||||||||
