Product Summary

The PMBT3904 is a NPN switching transistor in a SOT23 plastic package. PNP complement: PMBT3906. Application is Telephony and professional communication equipment.

Parametrics

PMBT3904 absolute maximum ratings: (1)VCBO collector-base voltage open emitter: 60 V; (2)VCEO collector-emitter voltage open base: 40 V; (3)VEBO emitter-base voltage open collector: 6 V; (4)IC collector current (DC): 100 mA; (5)ICM peak collector current: 200 mA; (6)IBM peak base current: 100 mA; (7)Ptot total power dissipation Tamb 25 °C: 250 mW; (8)Tstg storage temperature: -65 to +150 °C; (9)Tj junction temperature: 150 °C; (10)Tamb operating ambient temperature: -65 to +150 °C.

Features

PMBT3904 features: (1)Low current (max. 100 mA); (2)Low voltage (max. 40 V).

Diagrams

PMBT3904 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
PMBT3904
PMBT3904

Other


Data Sheet

Negotiable
PMBT3904 /T3
PMBT3904 /T3

NXP Semiconductors

Transistors Bipolar (BJT) TRANS SW TAPE-11

Data Sheet

Negotiable
PMBT3904,235
PMBT3904,235

NXP Semiconductors

Transistors Bipolar (BJT) TRANS SW TAPE-11

Data Sheet

0-1: $0.04
1-25: $0.03
25-250: $0.02
250-500: $0.02
PMBT3904,215
PMBT3904,215

NXP Semiconductors

Transistors Bipolar (BJT) NPN SW 200MA 40V

Data Sheet

0-1: $0.03
1-25: $0.01
25-250: $0.01
250-500: $0.01
PMBT3904M,315
PMBT3904M,315

NXP Semiconductors

Transistors Bipolar (BJT) GENERAL PURPOSE TRANSISTOR

Data Sheet

0-1: $0.03
1-25: $0.02
25-100: $0.02
100-250: $0.02
PMBT3904D
PMBT3904D

Other


Data Sheet

Negotiable
PMBT3904VS,115
PMBT3904VS,115

NXP Semiconductors

Transistors Bipolar (BJT) GENERAL PURPOSE TRANSISTOR

Data Sheet

0-1: $0.03
1-25: $0.02
25-100: $0.02
100-250: $0.02
PMBT3904YS,115
PMBT3904YS,115

NXP Semiconductors

Transistors Bipolar (BJT) GENERAL PURPOSE TRANSISTOR

Data Sheet

0-1: $0.03
1-25: $0.02
25-100: $0.02
100-250: $0.02
